High Speed Spindle Motor for Dental Mill machine 60000Rpm Electric Spindle Denture Milling Zirconia Wax PMMA PEEK

High Speed Spindle Motor for Dental Mill machine 60000Rpm Electric Spindle Denture Milling Zirconia Wax PMMA PEEK

Products - Engraving and milling spindle
  • Application Material
    Zirconia Wax PMMA PEEK
  • Applicable Industries
    Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Printing Shops, Construction Works , Energy & Mining
  • Weight (KG)
    3.97
  • Showroom Location
    None
  • Video Outgoing-inspection
    Provided
  • Machinery Test Report
    Provided
  • Marketing Type
    New Product 2024
  • Application
    DRILLING
  • Maximum Torque
    0.19N.M
  • Drive
    Motor
  • Operating Speed
    60000RPM
  • Warranty
    1 Year
  • Core Components
    Bearing, Motor, Gear
  • Voltage
    200V(3~)
  • Frequency
    1000HZ
  • Current
    4.3A
  • Cooling Method
    Water Cooling
  • Speed
    60000 Rpm
  • Collet
    3mm/3.175mm/4mm/6mm
  • Balance Grade
    G1
  • Spindle Outer Diameter
    61.9mm
  • Shaft Cone End Runout
    Within 1μm
  • Place of Origin
    guangzhou,china
  • Brand Name
    DECI
  • Price
    $1,300.00/sets 1-4 sets

High Speed Spindle Motor for Dental Mill machine 60000Rpm Electric Spindle Denture Milling Zirconia Wax PMMA PEEK

  • High Speed Spindle Motor for Dental Mill machine 60000Rpm Electric Spindle Denture Milling Zirconia Wax PMMA PEEK
  • High Speed Spindle Motor for Dental Mill machine 60000Rpm Electric Spindle Denture Milling Zirconia Wax PMMA PEEK
  • High Speed Spindle Motor for Dental Mill machine 60000Rpm Electric Spindle Denture Milling Zirconia Wax PMMA PEEK
  • High Speed Spindle Motor for Dental Mill machine 60000Rpm Electric Spindle Denture Milling Zirconia Wax PMMA PEEK
  • High Speed Spindle Motor for Dental Mill machine 60000Rpm Electric Spindle Denture Milling Zirconia Wax PMMA PEEK
Get Price Contact Now
DC-62G1
Parameters
Moter Power(KW)
2.2/1.8/1.5/1.2
Rated voltage (V/AC)
220



Maximum speed(Rpm)
60000
Maximum current (A)
7.2/6.5/5.0/4.3



Maximum frequency (Hz)
1000
Torque (N·M)
0.35/0.28/0.24/0.19



Technical parameters
Shaft Rotation Accuracy (mm)
≤ 0.001
Tooling Releasing pressure (Kgf/cm²)
5.0-6.0



Tooling Exchange Method
ATC
Front curtain pressure (Kgf/cm²)
2.5-3.0



Tooling Pulling Force(≥N)
1200
Tool return pressure(Kgf/cm²)
—



Tooling Connection
3mm-6mm collet chuck
Cooling method
Water cooling



Encoder (Optional)
—
Coolant Pressure (Kgf/cm²)
≥ 2.5



Proximity switch
—
Bearing lubrication mode
Grease



Balance Level
G1
Tooling Installation Method
Clamp



Vibration value (mm/s)
≤ 0.8
Weigh (Kg)
3.9



High Speed Spindle Motor for Dental Mill machine 60000Rpm Electric Spindle Denture Milling Zirconia Wax PMMA PEEK 0
High Speed Spindle Motor for Dental Mill machine 60000Rpm Electric Spindle Denture Milling Zirconia Wax PMMA PEEK 1
High Speed Spindle Motor for Dental Mill machine 60000Rpm Electric Spindle Denture Milling Zirconia Wax PMMA PEEK 2
High Speed Spindle Motor for Dental Mill machine 60000Rpm Electric Spindle Denture Milling Zirconia Wax PMMA PEEK 3
High Speed Spindle Motor for Dental Mill machine 60000Rpm Electric Spindle Denture Milling Zirconia Wax PMMA PEEK 4
High Speed Spindle Motor for Dental Mill machine 60000Rpm Electric Spindle Denture Milling Zirconia Wax PMMA PEEK 5
High Speed Spindle Motor for Dental Mill machine 60000Rpm Electric Spindle Denture Milling Zirconia Wax PMMA PEEK 6
High Speed Spindle Motor for Dental Mill machine 60000Rpm Electric Spindle Denture Milling Zirconia Wax PMMA PEEK 7
Q: Are you trading company or manufacturer ?
A: We are the only factory for DECI brand.

Q: do you have other spare parts for the spindle motor, like a grab, a VFD, a chuck?
A: We have all the packages. We can get the engineer to program you.

Q: What's your delivery time?
A: It depends. If your order is standard and in stock,we can deliver immediately. If not, about 7
    work days.

Q: Do you provide samples ? Is it free or extra ?
A: Sorry, we don't offer samples.

Q: Which payment method and Express can you accept?
A: 1. Payment: T/T,e-checking, Paypal, Western union, Alipay and etc.
    2. Express: UPS, DHL, FEDEX, TNT, EMS and etc.

Q: How do you make our business long-term and good relationship?
A: 1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends
with them, no matter where they come from.
