Water Cooling CNC ATC Drilling Spindle Motor for Milling 40000Rpm 380/220V 4.0/3.7/2.5KW

Water Cooling CNC ATC Drilling Spindle Motor for Milling 40000Rpm 380/220V 4.0/3.7/2.5KW

Products - Engraving and milling spindle
  • Condition
    New
  • Applicable Industries
    Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Printing Shops, Construction Works , Energy & Mining, Medical
  • Showroom Location
    None
  • Video Outgoing-inspection
    Not Available
  • Machinery Test Report
    Provided
  • Marketing Type
    New Product 2020
  • Application
    Runing, Milling, Drilling, Boring, For CNC Machine To Truning
  • Maximum Torque
    1.27N.M
  • Drive
    Motor
  • Operating Speed
    40000rpm
  • Warranty
    6 Months
  • Core Components
    Bearing, Motor
  • Product Name
    Milling Spindle
  • Diameter
    80mm
  • Power
    4.0/3.7/2.5kw
  • Voltage
    380/220(3~)
  • Frequency
    1333HZ
  • Current
    7.5/7.1/4.8A
  • Weight
    7.8kg
  • Cooling Method
    Water Cooling
  • Tooling Exchange Method
    ATC
  • Installation Method
    Mechanical Clip
  • After Warranty Service
    Video Technical Support, Online Support
  • Local Service Location
    None
  • After-sales Service Provided
    Free Spare Parts, Online Support
  • Place of Origin
    Guangzhou,china
  • Brand Name
    DECI
  • Model Number
    DC-80C
  • Price
    $1,276.20/sets 1-9 sets
  • Supply Ability
    500 Set/Sets per Month

Water Cooling CNC ATC Drilling Spindle Motor for Milling 40000Rpm 380/220V 4.0/3.7/2.5KW

  • Water Cooling CNC ATC Drilling Spindle Motor for Milling 40000Rpm 380/220V 4.0/3.7/2.5KW
  • Water Cooling CNC ATC Drilling Spindle Motor for Milling 40000Rpm 380/220V 4.0/3.7/2.5KW
  • Water Cooling CNC ATC Drilling Spindle Motor for Milling 40000Rpm 380/220V 4.0/3.7/2.5KW
  • Water Cooling CNC ATC Drilling Spindle Motor for Milling 40000Rpm 380/220V 4.0/3.7/2.5KW
  • Water Cooling CNC ATC Drilling Spindle Motor for Milling 40000Rpm 380/220V 4.0/3.7/2.5KW
  • Water Cooling CNC ATC Drilling Spindle Motor for Milling 40000Rpm 380/220V 4.0/3.7/2.5KW
Get Price Contact Now
Product Description
big power  40000Rmp 380/220V 4.0/3.7/2.5KW water cooling cnc atc drilling spindle motor for milling
This product is a metal cutting high-speed electric spindle with a maximum speed of 40,000 rpm and a rated power of 4 KW. It is suitable for high-speed, high-precision drilling, milling and grinding of metal and non-metal materials.

DECI spindle Motor Feature
1) Imported bearings with good quality, long working life.
2) Application: Milling,Engraving,Drilling in all kinds of CNC Router machine.
3) There are water cooling spindle, air cooling spindle and self cooling spindle for your choose.
4) Every spindle motor could be passed polishing process, Improve spindle concentricity to increase motor working life.

Water Cooling CNC ATC Drilling Spindle Motor for Milling 40000Rpm 380/220V 4.0/3.7/2.5KW 0
Water Cooling CNC ATC Drilling Spindle Motor for Milling 40000Rpm 380/220V 4.0/3.7/2.5KW 1
Water Cooling CNC ATC Drilling Spindle Motor for Milling 40000Rpm 380/220V 4.0/3.7/2.5KW 2
DECI   DC-80C
Parameters
Motor Power:
4/3.7/2.5KW
Rated voltage:
380/220V(3~)



Max rotate speed :
40000Rpm/min
Max currency:
7.5/7.1/4.8A



Max Frequency:
1333Hz
Torque:
1.27/0.88/0.6N.M



Specification
Shaft-end Cone Run-out:
≤0.001mm
Tooling Releasing Air Pressure:
5.6-6.0 Kgf/cm²



Tooling Exchange Method:
ATC
Air curtain pressure at front end:
2.5~3.0 Kgf/cm²



Tooling Pulling Force:
≥1600
Tooling Back Air Pressure:
─



Tooling Connection:
Φ6/8/10 Collet Chuck
Cooling:
water cooling



Encoder:
─
Coolant Pressure:
≥2.5 Kgf/cm²



Approach Switch:
─
Bearing Lubrication Method:
Grease



Balance Level :
G1
Tooling Instalation Method:
Mechanical clip



Vibration Value:
≤0.8
Weight:
7.8kg



Water Cooling CNC ATC Drilling Spindle Motor for Milling 40000Rpm 380/220V 4.0/3.7/2.5KW 3
Water Cooling CNC ATC Drilling Spindle Motor for Milling 40000Rpm 380/220V 4.0/3.7/2.5KW 4
Packing&Shipping
Packed in export standard carton or plywood case with PP bag, thick foam.
DECI Spindle / cnc in Machining.
atc cnc 4 axis
atc spindle cnc router
Water Cooling CNC ATC Drilling Spindle Motor for Milling 40000Rpm 380/220V 4.0/3.7/2.5KW 5
Related Products
Applicable industry
Water Cooling CNC ATC Drilling Spindle Motor for Milling 40000Rpm 380/220V 4.0/3.7/2.5KW 6
Why Choose Us
Water Cooling CNC ATC Drilling Spindle Motor for Milling 40000Rpm 380/220V 4.0/3.7/2.5KW 7
Company Profile
Water Cooling CNC ATC Drilling Spindle Motor for Milling 40000Rpm 380/220V 4.0/3.7/2.5KW 8
DECI Brand
Guangzhou Ruiheng Technology Co., Ltd is located in the Eastern Development Zone of Guangzhou. The company was established in 2009. We are a national high-tech enterprise integrating R&D, production, sales and maintenance of high-speed electric spindle. With the concerted efforts of all employees, a number of self-developed patented products, and the rapid development of the industry, the product quality and accuracy requirements are getting higher and higher. For this reason, the company has introduced advanced high-precision production of Swiss, German, British, Korean and other technologies for the electric spindle. Equipment and testing and calibration equipment, with the goal of "doing fine, coming stronger and bigger", more than 60% of our products are exported to the United States, Europe, India, Brazil, Dubai and other countries to help customers continuously update with quality service. Work hand in hand with customers, develop together, use morality as a product, and create a first-class product with magnetic "DECI" to help China create!
Water Cooling CNC ATC Drilling Spindle Motor for Milling 40000Rpm 380/220V 4.0/3.7/2.5KW 9
Water Cooling CNC ATC Drilling Spindle Motor for Milling 40000Rpm 380/220V 4.0/3.7/2.5KW 10
Water Cooling CNC ATC Drilling Spindle Motor for Milling 40000Rpm 380/220V 4.0/3.7/2.5KW 11
Certifications
Water Cooling CNC ATC Drilling Spindle Motor for Milling 40000Rpm 380/220V 4.0/3.7/2.5KW 12
FAQ
Q1:Are you a trading company or a manufacturer?
A1: We are the manufacturer of DECI electric spindles.

Q2:Do you have the products in stock?
A2:Our products are manufactured according to your order required except normal products.

Q3:Can I get some samples first?
A3: We can supply the sample if in stock, but the customers have to pay the sample cost and the courier cost..

Q4:How does your factory do regarding quality control?
A4:Quality is priority. Quality first. We We have been paying close attention to the quality control in the production process to ensure each product passes various tests before shipping.

Q5.How about the warranty of the products?
A5: We offer 12 months of technical service and after-sales service. If any problem about the machine after receivd, feel free to contact us.

Q6:How do you make our business long-term and good relationship?
A6:1.DECI keep good quality and competitive price to ensure our customers benefit ;
2.We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
