DECI high speed 40000Rmp 380/220V 4.0/3.7/2.5KW water cooling cnc atc drilling spindle motor for lathe milling clip spindle

DECI high speed 40000Rmp 380/220V 4.0/3.7/2.5KW water cooling cnc atc drilling spindle motor for lathe milling clip spindle

Products - Engraving and milling spindle
  • Condition
    New
  • Applicable Industries
    Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Printing Shops, Construction Works , Energy & Mining, Medical
  • Weight (KG)
    7.8
  • Showroom Location
    None
  • Video Outgoing-inspection
    Not Available
  • Machinery Test Report
    Provided
  • Marketing Type
    New Product 2020
  • Application
    Runing, Milling, Drilling, Boring, For CNC Machine To Truning
  • Maximum Torque
    1.27N.M
  • Drive
    Motor
  • Operating Speed
    40000rpm
  • Warranty
    6 Months
  • Core Components
    Bearing, Motor
  • Product Name
    Milling Spindle
  • Diameter
    80mm
  • Power
    4.0/3.7/2.5kw
  • Voltage
    380/220(3~)
  • Frequency
    1333HZ
  • Current
    7.5/7.1/4.8A
  • Weight
    7.8kg
  • Cooling Method
    Water Cooling
  • Tooling Exchange Method
    ATC
  • Installation Method
    Mechanical Clip
  • Port
    GUANGZHOU
  • Place of Origin
    Guangzhou,china
  • Brand Name
    DECI
  • Price
    $1,418.00/sets 1-9 sets
  • Supply Ability
    500 Set/Sets per Month

DECI high speed 40000Rmp 380/220V 4.0/3.7/2.5KW water cooling cnc atc drilling spindle motor for lathe milling clip spindle

  • DECI high speed 40000Rmp 380/220V 4.0/3.7/2.5KW water cooling cnc atc drilling spindle motor for lathe milling clip spindle
  • DECI high speed 40000Rmp 380/220V 4.0/3.7/2.5KW water cooling cnc atc drilling spindle motor for lathe milling clip spindle
  • DECI high speed 40000Rmp 380/220V 4.0/3.7/2.5KW water cooling cnc atc drilling spindle motor for lathe milling clip spindle
  • DECI high speed 40000Rmp 380/220V 4.0/3.7/2.5KW water cooling cnc atc drilling spindle motor for lathe milling clip spindle
  • DECI high speed 40000Rmp 380/220V 4.0/3.7/2.5KW water cooling cnc atc drilling spindle motor for lathe milling clip spindle
  • DECI high speed 40000Rmp 380/220V 4.0/3.7/2.5KW water cooling cnc atc drilling spindle motor for lathe milling clip spindle
Get Price Contact Now
Product Description
big power 40000Rmp 380/220V 4.0/3.7/2.5KW water cooling cnc atc drilling spindle motor for milling
This product is a metal cutting high-speed electric spindle with a maximum speed of 40,000 rpm and a rated power of 4 KW. It is suitable for high-speed, high-precision drilling, milling and grinding of metal and non-metal materials.

DECI spindle Motor Feature
1) Imported bearings with good quality, long working life.
2) Application: Milling,Engraving,Drilling in all kinds of CNC Router machine.
3) There are water cooling spindle, air cooling spindle and self cooling spindle for your choose.
4) Every spindle motor could be passed polishing process, Improve spindle concentricity to increase motor working life.

DECI high speed 40000Rmp 380/220V 4.0/3.7/2.5KW water cooling cnc atc drilling spindle motor for lathe milling clip spindle 0
DECI high speed 40000Rmp 380/220V 4.0/3.7/2.5KW water cooling cnc atc drilling spindle motor for lathe milling clip spindle 1
DECI high speed 40000Rmp 380/220V 4.0/3.7/2.5KW water cooling cnc atc drilling spindle motor for lathe milling clip spindle 2
DECI   DC-80C
Parameters
Motor Power:
4/3.7/2.5KW
Rated voltage:
380/220V(3~)
Max rotate speed :
40000Rpm/min
Max currency:
7.5/7.1/4.8A
Max Frequency:
1333Hz
Torque:
1.27/0.88/0.6N.M
Specification
Shaft-end Cone Run-out:
≤0.001mm
Tooling Releasing Air Pressure:
5.6-6.0 Kgf/cm²
Tooling Exchange Method:
ATC
Air curtain pressure at front end:
2.5~3.0 Kgf/cm²
Tooling Pulling Force:
≥1600
Tooling Back Air Pressure:
─
Tooling Connection:
Φ6/8/10 Collet Chuck
Cooling:
water cooling
Encoder:
─
Coolant Pressure:
≥2.5 Kgf/cm²
Approach Switch:
─
Bearing Lubrication Method:
Grease
Balance Level :
G1
Tooling Instalation Method:
Mechanical clip
Vibration Value:
≤0.8
Weight:
7.8kg
DECI high speed 40000Rmp 380/220V 4.0/3.7/2.5KW water cooling cnc atc drilling spindle motor for lathe milling clip spindle 3
DECI high speed 40000Rmp 380/220V 4.0/3.7/2.5KW water cooling cnc atc drilling spindle motor for lathe milling clip spindle 4
Packing&Shipping
Packed in export standard carton or plywood case with PP bag, thick foam.
