80MM 1.0KW 380V Water Electric milling copper aluminum Spindle Motor for CNC Router Tools

80MM 1.0KW 380V Water Electric milling copper aluminum Spindle Motor for CNC Router Tools

  • Condition
    New
  • Applicable Industries
    Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Printing Shops, Construction Works , Energy & Mining, Medical
  • Weight (KG)
    7.8
  • Showroom Location
    None
  • Video Outgoing-inspection
    Provided
  • Machinery Test Report
    Provided
  • Marketing Type
    New Product 2024
  • Application
    Runing, Milling, Drilling, Boring, For CNC Machine To Truning
  • Maximum Torque
    0.96 N.M
  • Drive
    Motor
  • Operating Speed
    18000rpm
  • Warranty
    1 Year
  • Core Components
    Bearing, Motor
  • Product Name
    Atc Spindle Motor
  • Power
    1.0 Kw
  • Voltage
    380
  • Frequency
    334HZ
  • Current
    1.5A
  • Weight
    7.8kg
  • Cooling Method
    Water Cooling
  • Tooling Exchange Method
    ATC
  • Installation Method
    Clamping
  • Place of Origin
    Guangzhou,china
  • Brand Name
    DECI
  • Price
    $1,240.00/sets 1-9 sets
  • Supply Ability
    500 Set/Sets per Month

80MM 1.0KW 380V Water Electric milling copper aluminum Spindle Motor for CNC Router Tools

Product Description

DECI ATC water cooled spindle motor 18000rpm  1KW CNC Router cnc milling machine

This product is a high speed motor spindle with a maximum speed of 18000 rpm.

It is suitable for high speed, high precision and high stable sense of milling, drilling and tapping of metal and non-metal materials.



DECI spindle Motor Feature

1) Imported bearings with good quality, long working life.

2) Application: Milling,Engraving,Drilling in all kinds of CNC Router machine.

3) There are water cooling spindle, air cooling spindle and self cooling spindle for your choose.

4) Every spindle motor could be passed polishing process, Improve spindle concentricity to increase motor working life.





Specificiations

80MM 1.0KW 380V Water Mini Cooled Electric milling copper&aluminum Spindle Motor For Cnc Router Tools80MM 1.0KW 380V Water Mini Cooled Electric milling copper&aluminum Spindle Motor For Cnc Router Tools





DECI DC-80D
Parameters
Motor Power: 1KW  Rated voltage: 380
 Max rotate speed : 18000Rpm/min  Max currency: 4.5A
 Max Frequency: 334Hz  Torque: 0.96N.M
Specification
Shaft-end Cone Run-out:  ≤0.001mm Tooling Releasing  Air Pressure: 5.6-6.0 Kgf/cm²
 Tooling Exchange Method:  ATC Air curtain pressure at front end: 2.5-3.0 Kgf/cm²
 Tooling Pulling Force: ≥1600 N Tooling Back Air Pressure: ~
 Tooling Connection: Φ6/8/10 Collet Chuck Cooling method: Water cooling
 Encoder: N/M Coolant Pressure: ≥2.5 Kgf/cm²
 Approach Switch: N/M Bearing Lubrication Method: Grease
Balance Level :  G1 Tooling Instalation Method: Mechanical clip
Vibration Value:  ≤0.8 Weight: 7.8kg

Applicable industry

80MM 1.0KW 380V Water Mini Cooled Electric milling copper&aluminum Spindle Motor For Cnc Router Tools

Packaging & Shipping

80MM 1.0KW 380V Water Mini Cooled Electric milling copper&aluminum Spindle Motor For Cnc Router Tools

Why choose us

80MM 1.0KW 380V Water Mini Cooled Electric milling copper&aluminum Spindle Motor For Cnc Router Tools

Company Profile

80MM 1.0KW 380V Water Mini Cooled Electric milling copper&aluminum Spindle Motor For Cnc Router Tools 80MM 1.0KW 380V Water Mini Cooled Electric milling copper&aluminum Spindle Motor For Cnc Router Tools

Certifications

80MM 1.0KW 380V Water Mini Cooled Electric milling copper&aluminum Spindle Motor For Cnc Router Tools

FAQ

Q1:Are you a trading company or a manufacturer ?
A1: We are the manufacturer of DECI electric spindles.



Q2:Do you have the products in stock?

A2:Our products are manufactured according to your order required except normal products.


Q3:Can I get some samples first?

A3: We can supply the sample if in stock, but the customers have to pay the sample cost and the courier cost..


Q4:How does your factory do regarding quality control?
A4:Quality is priority. Quality first. We have been paying close attention to the quality control in the production process to ensure each product passes various tests before shipping.

Q5.How about the warranty of the products?

A5: We offer 12 months of technical service and after-sales service. If any problem about the machine after receivd, feel free to contact us.


Q6:How do you make our business long-term and good relationship?
A6:1.DECI keep good quality and competitive price to ensure our customers benefit ;
      2.We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
