1 Micron Accuracy 20KW 20000Rpm Water Cooled Metal Milling Spindle Motor for Lathe Processing HSK 63A electric

1 Micron Accuracy 20KW 20000Rpm Water Cooled Metal Milling Spindle Motor for Lathe Processing HSK 63A electric

Products - Metal cut spindle motor
  • Condition
    New
  • Range Of Spindle Speed(r.p.m)
    0 - 20000 R.p.m
  • Video Outgoing-inspection
    Provided
  • Machinery Test Report
    Provided
  • Marketing Type
    Hot Product 2024
  • Warranty Of Core Components
    1 Year
  • Core Components
    Engine, Bearing, Gearbox, Motor, Gear
  • Dimension(L*W*H)
    624.1*150
  • Weight (KG)
    50.5
  • Repeatability (X/Y/Z) (mm)
    0.001
  • Positioning Accuracy (mm)
    0.01 Mm
  • Spindle Power (kW)
    20
  • Warranty
    1 Year
  • Key Selling Points
    High-accuracy
  • Application
    Other Applications, Hard Materials, 3C Accessories, Medical Industry
  • Showroom Location
    None
  • Type
    CNC Milling Machine
  • Machine Name
    CNC Milling
  • Function
    Milling Engraving
  • Keyword
    High Speed Cnc Milling Machine
  • Material
    Aluminum+Iron
  • Model No
    DC-150AZS-HSK63A
  • Processing Method
    AUTO Milling
  • Model
    DC-150
  • Automatic Grade
    Automatic Grade
  • Usage
    Steel
  • Place of Origin
    Guangdong, China
  • Brand Name
    DECI
  • Price
    $4,637.00/units 1-49 units
  • Packaging Details
    We can ship according to our customers.

1 Micron Accuracy 20KW 20000Rpm Water Cooled Metal Milling Spindle Motor for Lathe Processing HSK 63A electric

  • 1 Micron Accuracy 20KW 20000Rpm Water Cooled Metal Milling Spindle Motor for Lathe Processing HSK 63A electric
  • 1 Micron Accuracy 20KW 20000Rpm Water Cooled Metal Milling Spindle Motor for Lathe Processing HSK 63A electric
  • 1 Micron Accuracy 20KW 20000Rpm Water Cooled Metal Milling Spindle Motor for Lathe Processing HSK 63A electric
  • 1 Micron Accuracy 20KW 20000Rpm Water Cooled Metal Milling Spindle Motor for Lathe Processing HSK 63A electric
  • 1 Micron Accuracy 20KW 20000Rpm Water Cooled Metal Milling Spindle Motor for Lathe Processing HSK 63A electric
  • 1 Micron Accuracy 20KW 20000Rpm Water Cooled Metal Milling Spindle Motor for Lathe Processing HSK 63A electric
Get Price Contact Now
DC-150AYCZS-HSK63A
Parameters
Moter Power(KW)
20(pm synchronous )
Rated voltage (V/AC)
380 / 220



Maximum speed(Rpm)
20000
Maximum current (A)
57



Maximum frequency (Hz)
1000
Torque (N·M)
35



Technical parameters
Shaft Rotation Accuracy (mm)
≤ 0.001
Tooling Releasing pressure (Kgf/cm²)
50-80



Tooling Exchange Method
ATC
Front curtain pressure (Kgf/cm²)
2.5-3.0



Tooling Pulling Force(≥N)
≥ 18000
Tool return pressure(Kgf/cm²)
5.6-6.0



Tooling Connection
HSK63A
Cooling method
Water cooling



Encoder (Optional)
 Sin or Cos, 1 VPP
Coolant Pressure (Kgf/cm²)
-



Proximity switch
PNP
Bearing lubrication mode
Grease



Balance Level
G1
Tooling Installation Method
Flange



Vibration value (mm/s)
≤ 0.8
Weigh (Kg)
50.5



1 Micron Accuracy 20KW 20000Rpm Water Cooled Metal Milling Spindle Motor for Lathe Processing HSK 63A electric 0
1 Micron Accuracy 20KW 20000Rpm Water Cooled Metal Milling Spindle Motor for Lathe Processing HSK 63A electric 1
1 Micron Accuracy 20KW 20000Rpm Water Cooled Metal Milling Spindle Motor for Lathe Processing HSK 63A electric 2
1 Micron Accuracy 20KW 20000Rpm Water Cooled Metal Milling Spindle Motor for Lathe Processing HSK 63A electric 3
1 Micron Accuracy 20KW 20000Rpm Water Cooled Metal Milling Spindle Motor for Lathe Processing HSK 63A electric 4
1 Micron Accuracy 20KW 20000Rpm Water Cooled Metal Milling Spindle Motor for Lathe Processing HSK 63A electric 5
1 Micron Accuracy 20KW 20000Rpm Water Cooled Metal Milling Spindle Motor for Lathe Processing HSK 63A electric 6
1 Micron Accuracy 20KW 20000Rpm Water Cooled Metal Milling Spindle Motor for Lathe Processing HSK 63A electric 7
Q: Are you trading company or manufacturer ?
A: We are the only factory for DECI brand.

Q: do you have other spare parts for the spindle motor, like a grab, a VFD, a chuck?
A: We have all the packages. We can get the engineer to program you.

Q: What's your delivery time?
A: It depends. If your order is standard and in stock,we can deliver immediately. If not, about 7
    work days.

Q: Do you provide samples ? Is it free or extra ?
A: Sorry, we don't offer samples.

Q: Which payment method and Express can you accept?
A: 1. Payment: T/T,e-checking, Paypal, Western union, Alipay and etc.
    2. Express: UPS, DHL, FEDEX, TNT, EMS and etc.

Q: How do you make our business long-term and good relationship?
A: 1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends
with them, no matter where they come from.
