DECI BT30 ATC 7.5KW 30000Rpm Spindle Motor for CNC Engraving PNP Water Cooled Flange

DECI BT30 ATC 7.5KW 30000Rpm Spindle Motor for CNC Engraving PNP Water Cooled Flange

Products - Engraving and milling spindle
  • Condition
    New
  • Applicable Industries
    Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Printing Shops, Construction Works , Energy & Mining, Medical
  • Weight (KG)
    26
  • Showroom Location
    None
  • Video Outgoing-inspection
    Provided
  • Machinery Test Report
    Provided
  • Marketing Type
    New Product 2023
  • Application
    Runing, Milling, Drilling, Boring, For CNC Machine To Truning
  • Maximum Torque
    5.73N.M
  • Drive
    Motor
  • Operating Speed
    30000rpm
  • Warranty
    6 Months
  • Core Components
    Bearing, Motor
  • Product Name
    High Speed Spindle Motor
  • Power
    7.5/5.5KW
  • Voltage
    380/220(3~)
  • Frequency
    1000HZ
  • Current
    25A
  • Key Word
    Atc Bt30 Spindle
  • Cooling Method
    Water Cooling
  • Tooling Exchange Method
    ATC
  • Installation Method
    FLANGE
  • Diameter
    120mm
  • Place of Origin
    Guangzhou,china
  • Brand Name
    DECI
  • Price
    $1,999.71/sets 1-9 sets
  • Supply Ability
    500 Set/Sets per Month

DECI BT30 ATC 7.5KW 30000Rpm Spindle Motor for CNC Engraving PNP Water Cooled Flange

  • DECI BT30 ATC 7.5KW 30000Rpm Spindle Motor for CNC Engraving PNP Water Cooled Flange
  • DECI BT30 ATC 7.5KW 30000Rpm Spindle Motor for CNC Engraving PNP Water Cooled Flange
  • DECI BT30 ATC 7.5KW 30000Rpm Spindle Motor for CNC Engraving PNP Water Cooled Flange
  • DECI BT30 ATC 7.5KW 30000Rpm Spindle Motor for CNC Engraving PNP Water Cooled Flange
  • DECI BT30 ATC 7.5KW 30000Rpm Spindle Motor for CNC Engraving PNP Water Cooled Flange
  • DECI BT30 ATC 7.5KW 30000Rpm Spindle Motor for CNC Engraving PNP Water Cooled Flange
Get Price Contact Now
Product Description
DECI High speed atc router BT30 ATC 7.5KW 30000Rmp for cnc machine spindle motor for engraving
DC-1230A BT30 ATC 7.5KW 30000Rmp spindle motor water cooling for metal machine machinery, the serious products of the motor spindles has been developed and tested for over ten years.
The key design of the structure, electrical circuit, internal sealing, lubrication, motor and collets has been authorized with
patents in China.

DECI spindle Motor Feature
1) Imported bearings with good quality, long working life.
2) Application: Milling,Engraving,Drilling in all kinds of CNC Router machine.
3) There are water cooling spindle, air cooling spindle and self cooling spindle for your choose.
4) Every spindle motor could be passed polishing process, Improve spindle concentricity to increase motor working life.

DECI   DC-1230A
Parameters
Motor Power:
7.5KW
Rated voltage:
380V(3~)



Max rotate speed :
30000Rpm/min
Max currency:
25A



Max Frequency:
1000Hz
Torque:
5.73N.M



Specification
Shaft-end Cone Run-out:
≤0.001mm
Tooling Releasing Air Pressure:
5.6-6.0 Kgf/cm²



Tooling Exchange Method:
ATC
Air curtain pressure at front end:
2.5~3.0 Kgf/cm²



Tooling Pulling Force:
2900
Tooling Back Air Pressure:
5.6-6.0 Kgf/cm²



Tooling Connection:
BT30
Cooling:
water cooling



Encoder:
Sine-Cosine 1VPP(Optional)
Coolant Pressure:
2.5 Kgf/cm²



Approach Switch:
PNP On
Bearing Lubrication Method:
Grease



Balance Level :
G1
Tooling Instalation Method:
FLANGE



Vibration Value:
≤0.8
Weight:
26kg



DECI BT30 ATC 7.5KW 30000Rpm Spindle Motor for CNC Engraving PNP Water Cooled Flange 0
DECI BT30 ATC 7.5KW 30000Rpm Spindle Motor for CNC Engraving PNP Water Cooled Flange 1
Packing&Shipping
Packed in export standard carton or plywood case with PP bag, thick foam.
DECI Spindle / bt30 atc spindle
atc spindle cnc machine
atc spindle encoder
DECI BT30 ATC 7.5KW 30000Rpm Spindle Motor for CNC Engraving PNP Water Cooled Flange 2
Related Products
Applicable industry
DECI BT30 ATC 7.5KW 30000Rpm Spindle Motor for CNC Engraving PNP Water Cooled Flange 3
Why Choose Us
DECI BT30 ATC 7.5KW 30000Rpm Spindle Motor for CNC Engraving PNP Water Cooled Flange 4
Company Profile
DECI BT30 ATC 7.5KW 30000Rpm Spindle Motor for CNC Engraving PNP Water Cooled Flange 5
DECI Brand
Guangzhou Ruiheng Technology Co., Ltd is located in the Eastern Development Zone of Guangzhou. The company was established in 2009. We are a national high-tech enterprise integrating R&D, production, sales and maintenance of high-speed electric spindle. With the concerted efforts of all employees, a number of self-developed patented products, and the rapid development of the industry, the product quality and accuracy requirements are getting higher and higher. For this reason, the company has introduced advanced high-precision production of Swiss, German, British, Korean and other technologies for the electric spindle. Equipment and testing and calibration equipment, with the goal of "doing fine, coming stronger and bigger", more than 60% of our products are exported to the United States, Europe, India, Brazil, Dubai and other countries to help customers continuously update with quality service. Work hand in hand with customers, develop together, use morality as a product, and create a first-class product with magnetic "DECI" to help China create!
DECI BT30 ATC 7.5KW 30000Rpm Spindle Motor for CNC Engraving PNP Water Cooled Flange 6
DECI BT30 ATC 7.5KW 30000Rpm Spindle Motor for CNC Engraving PNP Water Cooled Flange 7
DECI BT30 ATC 7.5KW 30000Rpm Spindle Motor for CNC Engraving PNP Water Cooled Flange 8
Certifications
DECI BT30 ATC 7.5KW 30000Rpm Spindle Motor for CNC Engraving PNP Water Cooled Flange 9
FAQ
Q1:Are you a trading company or a manufacturer?
A1: We are the manufacturer of DECI electric spindles.

Q2:Do you have the products in stock?
A2:Our products are manufactured according to your order required except normal products.

Q3:Can I get some samples first?
A3: We can supply the sample if in stock, but the customers have to pay the sample cost and the courier cost..

Q4:How does your factory do regarding quality control?
A4:Quality is priority. Quality first. We We have been paying close attention to the quality control in the production process to ensure each product passes various tests before shipping.

Q5.How about the warranty of the products?
A5: We offer 12 months of technical service and after-sales service. If any problem about the machine after receivd, feel free to contact us.

Q6:How do you make our business long-term and good relationship?
A6:1.DECI keep good quality and competitive price to ensure our customers benefit ;
2.We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
