DECI zirconia collet spindle 250W 72V 80000rpm Dental motor Pcb Teeth Milling Drilling Engraving Automatic Spindle Motor

DECI zirconia collet spindle 250W 72V 80000rpm Dental motor Pcb Teeth Milling Drilling Engraving Automatic Spindle Motor

Products - Dental spindle
  • Condition
    New
  • Applicable Industries
    Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Printing Shops, Construction Works , Energy & Mining, Other
  • Weight (KG)
    1.3
  • Showroom Location
    None
  • Video Outgoing-inspection
    Provided
  • Machinery Test Report
    Provided
  • Marketing Type
    New Product 2024
  • Application
    Milling
  • Maximum Torque
    0.04
  • Drive
    Motor
  • Operating Speed
    80000RPM
  • Warranty
    1 Year
  • Core Components
    Bearing, Gearbox, Motor, Gear
  • Power
    250W
  • Voltage
    72V(DC)
  • Frequency
    1333HZ
  • Current
    5.5A
  • Weight
    1.1KG
  • Cooling Method
    Air Cooling
  • Wattanty Period
    1 Year
  • Torque
    0.04
  • Joint Of Nose
    Collet
  • Cooling
    Air Coolded
  • Application Material
    Zirconia Wax PMMA PEEK
  • Place of Origin
    guangdong,china
  • Brand Name
    DECI
  • Price
    $1,405.00/sets 1-9 sets

DECI zirconia collet spindle 250W 72V 80000rpm Dental motor Pcb Teeth Milling Drilling Engraving Automatic Spindle Motor

  • DECI zirconia collet spindle 250W 72V 80000rpm Dental motor Pcb Teeth Milling Drilling Engraving Automatic Spindle Motor
  • DECI zirconia collet spindle 250W 72V 80000rpm Dental motor Pcb Teeth Milling Drilling Engraving Automatic Spindle Motor
  • DECI zirconia collet spindle 250W 72V 80000rpm Dental motor Pcb Teeth Milling Drilling Engraving Automatic Spindle Motor
  • DECI zirconia collet spindle 250W 72V 80000rpm Dental motor Pcb Teeth Milling Drilling Engraving Automatic Spindle Motor
  • DECI zirconia collet spindle 250W 72V 80000rpm Dental motor Pcb Teeth Milling Drilling Engraving Automatic Spindle Motor
  • DECI zirconia collet spindle 250W 72V 80000rpm Dental motor Pcb Teeth Milling Drilling Engraving Automatic Spindle Motor
Get Price Contact Now
DC-33A
Parameters
Moter Power(KW)
0.25
Rated voltage (V/AC)
72 DC
Maximum speed(Rpm)
80000
Maximum current (A)
5.5
Maximum frequency (Hz)
1333
Torque (N·M)
0.04
Technical parameters
Shaft Rotation Accuracy (mm)
≤ 0.001
Tooling Releasing pressure (Kgf/cm²)
5.0-6.0
Tooling Exchange Method
ATC
Front curtain pressure (Kgf/cm²)
—
Tooling Pulling Force(≥N)
1000
Tool return pressure(Kgf/cm²)
—
Tooling Connection
φ3.175/4 collet
Cooling method
Air cooling
Encoder (Optional)
—
Coolant Pressure (Kgf/cm²)
1.0-1.5
Proximity switch
—
Bearing lubrication mode
Grease
Balance Level
G1
Tooling Installation Method
Clamp
Vibration value (mm/s)
≤ 0.8
Weigh (Kg)
1.2
DECI zirconia collet spindle 250W 72V 80000rpm Dental motor Pcb Teeth Milling Drilling Engraving Automatic Spindle Motor 0
DECI zirconia collet spindle 250W 72V 80000rpm Dental motor Pcb Teeth Milling Drilling Engraving Automatic Spindle Motor 1
DECI zirconia collet spindle 250W 72V 80000rpm Dental motor Pcb Teeth Milling Drilling Engraving Automatic Spindle Motor 2
DECI zirconia collet spindle 250W 72V 80000rpm Dental motor Pcb Teeth Milling Drilling Engraving Automatic Spindle Motor 3
DECI zirconia collet spindle 250W 72V 80000rpm Dental motor Pcb Teeth Milling Drilling Engraving Automatic Spindle Motor 4
DECI zirconia collet spindle 250W 72V 80000rpm Dental motor Pcb Teeth Milling Drilling Engraving Automatic Spindle Motor 5
DECI zirconia collet spindle 250W 72V 80000rpm Dental motor Pcb Teeth Milling Drilling Engraving Automatic Spindle Motor 6
DECI zirconia collet spindle 250W 72V 80000rpm Dental motor Pcb Teeth Milling Drilling Engraving Automatic Spindle Motor 7
Q: Are you trading company or manufacturer ?
A: We are the only factory for DECI brand.

Q: do you have other spare parts for the spindle motor, like a grab, a VFD, a chuck?
A: We have all the packages. We can get the engineer to program you.

Q: What's your delivery time?
A: It depends. If your order is standard and in stock,we can deliver immediately. If not, about 7
work days.

Q: Do you provide samples ? Is it free or extra ?
A: Sorry, we don't offer samples.

Q: Which payment method and Express can you accept?
A: 1. Payment: T/T,e-checking, Paypal, Western union, Alipay and etc.
2. Express: UPS, DHL, FEDEX, TNT, EMS and etc.

Q: How do you make our business long-term and good relationship?
A: 1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends
with them, no matter where they come from.
