DC-38 750W Dental Milling Spindle Motor for Processing Soft Materials Zirconia Wax PMMA PEEK Denture Machine

DC-38 750W Dental Milling Spindle Motor for Processing Soft Materials Zirconia Wax PMMA PEEK Denture Machine

Products - Dental Milling Machine Spindle
  • Applicable Industries
    Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Printing Shops, Construction Works , Energy & Mining, Medical
  • Weight (KG)
    5
  • Application
    Dentures
  • Maximum Torque
    0.12N.M
  • Drive
    Motor
  • Operating Speed
    40000rpm
  • Warranty
    1 Year
  • Core Components
    Bearing, Motor
  • Product Name
    Denture Spindle Motor
  • Diameter
    38mm
  • Power
    350W
  • Voltage
    100(3~)
  • Frequency
    1000HZ
  • Rotated Speed
    60000rpm
  • Current
    3.5A
  • Weight
    1.9kg
  • Cooling Method
    Air-cooled
  • Tooling Exchange Method
    ATC
  • Application Material
    Zirconia Wax PMMA PEEK
  • Place of Origin
    Guangzhou,china
  • Brand Name
    DECI
  • Price
    $1,120.05/sets 1-9 sets
  • Supply Ability
    500 Set/Sets per Month

DC-38 750W Dental Milling Spindle Motor for Processing Soft Materials Zirconia Wax PMMA PEEK Denture Machine

  • DC-38 750W Dental Milling Spindle Motor for Processing Soft Materials Zirconia Wax PMMA PEEK Denture Machine
  • DC-38 750W Dental Milling Spindle Motor for Processing Soft Materials Zirconia Wax PMMA PEEK Denture Machine
  • DC-38 750W Dental Milling Spindle Motor for Processing Soft Materials Zirconia Wax PMMA PEEK Denture Machine
  • DC-38 750W Dental Milling Spindle Motor for Processing Soft Materials Zirconia Wax PMMA PEEK Denture Machine
  • DC-38 750W Dental Milling Spindle Motor for Processing Soft Materials Zirconia Wax PMMA PEEK Denture Machine
  • DC-38 750W Dental Milling Spindle Motor for Processing Soft Materials Zirconia Wax PMMA PEEK Denture Machine
Get Price Contact Now
Product Description
DECI high quality air cooled 60000Rmp 750W spindle motor atc cnc Router denture machine
This product is a metal cutting high speed motor spindle with a maximum speed of 40000 rpm and a rated power of 750W. It is suitable for the processing of soft materials such as zirconia for denture machine and high precision cutting of PCB circuit board.

DECI spindle Motor Feature
1) Imported bearings with good quality, long working life.
2) Application: Milling,Engraving,Drilling in all kinds of CNC Router machine.
3) There are water cooling spindle, air cooling spindle and self cooling spindle for your choose.
4) Every spindle motor could be passed polishing process, Improve spindle concentricity to increase motor working life.

DC-38 750W Dental Milling Spindle Motor for Processing Soft Materials Zirconia Wax PMMA PEEK Denture Machine 0
DC-38 750W Dental Milling Spindle Motor for Processing Soft Materials Zirconia Wax PMMA PEEK Denture Machine 1
DC-38 750W Dental Milling Spindle Motor for Processing Soft Materials Zirconia Wax PMMA PEEK Denture Machine 2
DECI   DC-38
Parameters
Motor Power:
0.35KW
Rated voltage:
100v(3~)



Max rotate speed :
60000rpm/min
Max currency:
3.5A



Max Frequency:
1000Hz
Torque:
0.056N.M



Specification
Shaft-end Cone Run-out:
less than 0.001mm
Tooling Releasing Air Pressure:
5.0-6.0 Kgf/cm²



Tooling Exchange Method:
ATC
Air curtain pressure at front end:
__



Tooling Pulling Force:
≥1000 N
Tooling Back Air Pressure:
N/M



Tooling Connection:
Φ3/Φ3.175/4 Collet Chuck
Cooling:
Air-cooled



Encoder:
N/M
Coolant medium pressure:
1.0~1.5 Kgf/cm²



Approach Switch:
N/M
Bearing Lubrication Method:
Grease



Balance Level :
G1
Tooling Instalation Method:
Spindle holder clamp



Vibration Value:
≤0.8
Weight:
1.9kg



DC-38 750W Dental Milling Spindle Motor for Processing Soft Materials Zirconia Wax PMMA PEEK Denture Machine 3
