This product is a dental engraving electric spindle with a maximum speed of 30,000 rpm and a rated power of 0.35 kw. The denture engraving electric spindle is custom-made for engraving dental dentures. It is mainly used for the processing of soft materials such as zirconia of denture machines, and is widely used in the field of dentistry. It is specially designed for high-precision milling of various metals and non-metals.
Spindle Motor Feature
1) Imported bearings with good quality, long working life.
2) Application: Milling,Engraving,Drilling in all kinds of CNC Router machine.
3) There are water cooling spindle , air cooling spindle and self cooling spindle for your choose.
4) Every spindle motor must be passed polishing process, Improve spindle concentricity to increase motor working life.
More Spindle is also available with best price, if needed, welcome contact us.
1.water cooling:300w,800w,1.2kw,1.5kw,2.2kw,3kw,4kw,3.2kw,4.5kw,5.5kw
2.air cooling: 800w,1.5kw,2.2kw.3.5kw,4.5kw,6kw,7.5kw,12kw
3.cooled by self: 400w
4.ATC spindle: cooled by water: 1.5kw,2.2kw,5.5kw,6kw,7.5kw
cooled by air: 8kw,9kw (same HSD)
5.sealing side spindle:350w,550w,700w,750w,1.1kw,1.8kw,2.2kw
| DC-38-0.75FParameters Motor Power:0.5KW Rated voltage: 100V(3~) Max rotate speed :60000Rpm/min Max currency: 3.5A Max Frequency:1000Hz Torque: 0.056N.MSpecification Cone surface spring at shaft end: ≤0.001mmTooling Releasing Air curtain: 5.6-6.0 Kgf/cm² Tooling Exchange Method: ATCAir curtain pressure at front end: ~ Tooling Pulling Force: ≥1000NTooling Back Air Pressure: None Tooling Connection:φ3/φ3.175/φ4 Chuck CollectCooling: air cooling Encoder: NoneCoolant Pressure: 1.0~1.5Kgf/cm² Approach Switch: NoneBearing Lubrication Method: GreaseBalance Level : G1Tooling Instalation Method:Mechanical HoldingVibration Value: ≤0.8 mm/sWeight:1.9kg |
Q: Are you trading company or manufacturer ?
Q: Do you have other spare parts for the spindle motor, like a grab, a VFD, a chuck?
A: We have all the packages. We can get the engineer to program you.
Q: Do you provide samples ? is it free or extra ?
A: Sorry, we don't offer samples.
Q: Which payment method and Express can you accept?
1:Payment: T/T,e-checking, Paypal, Western union, Alipay and etc.
2:Express: UPS, DHL, FEDEX, TNT, EMS and etc.
Learn more details
Our products are sold all over the world, you can rest assured.
