High Speed 60000rpm 350W 120V Air Cooled ATC Spindle Motor for CNC Boring and Milling

High Speed 60000rpm 350W 120V Air Cooled ATC Spindle Motor for CNC Boring and Milling

Products - Dental Milling Machine Spindle
  • Condition
    New
  • Applicable Industries
    Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Printing Shops, Construction Works , Energy & Mining, Medical
  • Weight (KG)
    1.35
  • Showroom Location
    None
  • Video Outgoing-inspection
    Not Available
  • Machinery Test Report
    Provided
  • Marketing Type
    New Product 2020
  • Application
    Runing, Milling, Drilling, Boring, For CNC Machine To Truning
  • Maximum Torque
    0.056N.M
  • Drive
    Motor
  • Operating Speed
    60000rpm
  • Warranty
    1 Year
  • Core Components
    Bearing, Motor
  • Product Name
    Spindle Motor For Cnc Router
  • Diameter
    40mm
  • Power
    0.35kw
  • Voltage
    120(3~)
  • Frequency
    1000HZ
  • Current
    2.5A
  • Weight
    1.35kg
  • Cooling Method
    Air Cooling
  • Tooling Exchange Method
    ATC
  • Installation Method
    Clamp
  • Port
    GUANGZHOU
  • Application Material
    Zirconia Wax PMMA PEEK
  • Place of Origin
    Guangzhou,china
  • Brand Name
    DECI
  • Price
    $1,168.50/sets 1-9 sets
  • Supply Ability
    500 Set/Sets per Month

High Speed 60000rpm 350W 120V Air Cooled ATC Spindle Motor for CNC Boring and Milling

  • High Speed 60000rpm 350W 120V Air Cooled ATC Spindle Motor for CNC Boring and Milling
  • High Speed 60000rpm 350W 120V Air Cooled ATC Spindle Motor for CNC Boring and Milling
  • High Speed 60000rpm 350W 120V Air Cooled ATC Spindle Motor for CNC Boring and Milling
  • High Speed 60000rpm 350W 120V Air Cooled ATC Spindle Motor for CNC Boring and Milling
  • High Speed 60000rpm 350W 120V Air Cooled ATC Spindle Motor for CNC Boring and Milling
  • High Speed 60000rpm 350W 120V Air Cooled ATC Spindle Motor for CNC Boring and Milling
Get Price Contact Now
Product Description
60000rpm 350W 120V air cooling atc spindle motor for cnc router drilling and milling machine high speed
This product is a metal cutting high speed motor spindle with a maximum speed of 60000 rpm and a rated power of 350W. It is suitable for the processing of soft materials such as zirconia for denture machine and high precision cutting of PCB circuit board.

DECI spindle Motor Feature
1) Imported bearings with good quality, long working life.
2) Application: Milling,Engraving,Drilling in all kinds of CNC Router machine.
3) There are water cooling spindle, air cooling spindle and self cooling spindle for your choose.
4) Every spindle motor could be passed polishing process, Improve spindle concentricity to increase motor working life.

High Speed 60000rpm 350W 120V Air Cooled ATC Spindle Motor for CNC Boring and Milling 0
High Speed 60000rpm 350W 120V Air Cooled ATC Spindle Motor for CNC Boring and Milling 1
High Speed 60000rpm 350W 120V Air Cooled ATC Spindle Motor for CNC Boring and Milling 2
DECI   DC-40V5
Parameters
Motor Power:
0.35KW
Rated voltage:
120V(3~)
Max rotate speed :
60000Rpm/min
Max currency:
2.5A
Max Frequency:
1000Hz
Torque:
0.056N.M
Specification
Shaft-end Cone Run-out:
≤0.001mm
Tooling Releasing Air Pressure:
5.0-6.0 Kgf/cm²
Tooling Exchange Method:
ATC
Air curtain pressure at front end:
__
Tooling Pulling Force:
≥1000 N
Tooling Back Air Pressure:
N/M
Tooling Connection:
Φ4 Collet Chuck
Cooling:
Air cooling
Encoder:
N/M
Coolant Pressure:
2.5-3.0 Kgf/cm²
Approach Switch:
N/M
Bearing Lubrication Method:
Grease
Balance Level :
G1
Tooling Instalation Method:
Mechanical clip
Vibration Value:
≤0.8
Weight:
1.35kg
High Speed 60000rpm 350W 120V Air Cooled ATC Spindle Motor for CNC Boring and Milling 3
High Speed 60000rpm 350W 120V Air Cooled ATC Spindle Motor for CNC Boring and Milling 4
Packing&Shipping
We can ship according to our customers.
